SFCDC5000101MC1
RoHS
RoHS compliant
RoHS compliantPackage Axial, Bushing
Category Filters / Feed Through Capacitors
Description
SFCD Axial Bushing SILVER 1 Feed Through Capacitor 10A 10000MOhm 0.250Diax0.467L 6.35mmx11.85mm 4dB @ 100MHz
PDF
/
Buying Options
Total Price: USD $19.81
Unit Price: USD $19.806409
≥1 USD $19.806409
≥200 USD $7.666023
≥500 USD $7.395566
≥1000 USD $7.262963
Inventory: 7562
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Insulation Resistance-Min 10000MOhm
Insertion Loss 4dB @ 100MHz
Thread Size 12-32
Filter Type FEED THROUGH CAPACITOR
Current 10A
Inductance 0.75 μH
Number of Functions 1
Capacitance 100pF
Additional Feature C-TYPE CIRCUIT
Voltage - Rated 500V
Terminal Finish SILVER
Temperature Coefficient C0G NP0
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e4
Tolerance ±20%
Size / Dimension 0.250Diax0.467L 6.35mmx11.85mm
Series SFCD
Published 2014
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Package / Case Axial, Bushing
Mounting Type PANEL MOUNT
Supply Chain
Factory Lead Time 11 Weeks
