SFBML5000681MX0
RoHS
RoHS compliant
RoHS compliantPackage Axial, Bushing
Category Filters / Feed Through Capacitors
Description
SFBM Axial Bushing SILVER 1 Feed Through Capacitor 10A 10000MOhm 6.35mm 22dB @ 100MHz
PDF
/
Buying Options
Total Price: USD $40.63
Unit Price: USD $40.625065
≥1 USD $40.625065
≥200 USD $15.721978
≥500 USD $15.169247
≥1000 USD $14.896163
Inventory: 5131
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mounting Type PANEL MOUNT
Package / Case Axial, Bushing
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2014
Series SFBM
Size / Dimension 0.250Diax0.472L 6.35mmx12.00mm
Tolerance ±20%
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Temperature Coefficient X7R
Terminal Finish SILVER
Voltage - Rated 500V
Additional Feature L-C-TYPE CIRCUIT; TEMP CHARACTERISTIC CODE ALSO AVAILABLE IN C0G
Capacitance 680pF
Number of Functions 1
Physical Dimension D6.35XH12.0 (mm)/D0.25XH0.472 (inch)
Inductance 0.5 μH
Current 10A
Filter Type DATA LINE FILTER
Thread Size M5x0.8
Insertion Loss 22dB @ 100MHz
Insulation Resistance-Min 10000MOhm
Dimensions
Diameter 6.35mm
Height 12mm
Compliance
RoHS Status ROHS3 Compliant
