SFBML5000100ZC1
RoHS
RoHS compliant
RoHS compliantPackage Axial, Bushing
Category Filters / Feed Through Capacitors
Description
SFBM Axial Bushing SILVER 1 Feed Through Capacitor 10A 10000MOhm 6.35mm 0.5μH
PDF
/
Buying Options
Total Price: USD $20.16
Unit Price: USD $20.15958
≥1 USD $20.15958
≥200 USD $7.801252
≥500 USD $7.528169
≥1000 USD $7.391627
Inventory: 2995
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mounting Type PANEL MOUNT
Package / Case Axial, Bushing
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2014
Series SFBM
Size / Dimension 0.250Diax0.472L 6.35mmx12.00mm
Tolerance -20% +80%
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Temperature Coefficient C0G NP0
Terminal Finish SILVER
Voltage - Rated 500V
Additional Feature L-C-TYPE CIRCUIT
Capacitance 10pF
Number of Functions 1
Physical Dimension D6.35XH12.0 (mm)/D0.25XH0.472 (inch)
Inductance 0.5 μH
Current 10A
Filter Type DATA LINE FILTER
Thread Size M5x0.8
Insertion Loss (Max) 6 dB
Insulation Resistance-Min 10000MOhm
Dimensions
Diameter 6.35mm
Height 12mm
Compliance
RoHS Status ROHS3 Compliant
