SFBMC5000682MX1
RoHS
RoHS compliant
RoHS compliantPackage Axial, Bushing
Category Filters / Feed Through Capacitors
Description
SFBM Axial Bushing SILVER 1 Feed Through Capacitor 10A 10000MOhm 6.35mm 39dB @ 100MHz
PDF
/
Buying Options
Total Price: USD $39.81
Unit Price: USD $39.807128
≥1 USD $39.807128
≥200 USD $15.405569
≥500 USD $14.864654
≥1000 USD $14.596822
Inventory: 7948
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 12mm
Diameter 6.35mm
Technical
Insulation Resistance-Min 10000MOhm
Insertion Loss 39dB @ 100MHz
Thread Size M5x0.8
Filter Type FEED THROUGH CAPACITOR
Current 10A
Physical Dimension D6.35XH12.0 (mm)/D0.25XH0.472 (inch)
Number of Functions 1
Capacitance 6800pF
Additional Feature C-TYPE CIRCUIT
Voltage - Rated 500V
Terminal Finish SILVER
Temperature Coefficient X7R
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e4
Tolerance ±20%
Size / Dimension 0.250Diax0.472L 6.35mmx12.00mm
Series SFBM
Published 2014
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Package / Case Axial, Bushing
Mounting Type PANEL MOUNT
Supply Chain
Factory Lead Time 11 Weeks
