SFBLL5000680MC0
RoHS
RoHS compliant
RoHS compliantPackage Axial, Bushing
Category Filters / Feed Through Capacitors
Description
CAP FEEDTHRU 68PF 20% 500V AXIAL
PDF
/
Inventory: 1481
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mounting Type PANEL MOUNT
Package / Case Axial, Bushing
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2014
Series SFBL
Size / Dimension 0.187Diax0.362L 4.75mmx9.20mm
Tolerance ±20%
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Temperature Coefficient C0G NP0
Terminal Finish SILVER
Voltage - Rated 500V
Additional Feature L-C TYPE CIRCUIT
Capacitance 68pF
Number of Functions 1
Inductance 0.05 μH
Current 10A
Filter Type DATA LINE FILTER
Thread Size M4x0.7
Insertion Loss 4dB @ 100MHz
Output Impedance 50Ohm Ω
Insulation Resistance-Min 10000MOhm
Compliance
RoHS Status ROHS3 Compliant
