SFBLL5000150ZC0
RoHS
RoHS compliant
RoHS compliantPackage Axial, Bushing
Category Filters / Feed Through Capacitors
Description
SFBL Axial Bushing SILVER 1 Feed Through Capacitor 10A 10000MOhm 0.187Diax0.362L 4.75mmx9.20mm 0.05μH
PDF
/
Buying Options
Total Price: USD $34.55
Unit Price: USD $34.548964
≥1 USD $34.548964
≥200 USD $13.370574
≥500 USD $12.900555
≥1000 USD $12.668172
Inventory: 4173
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mounting Type PANEL MOUNT
Package / Case Axial, Bushing
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2014
Series SFBL
Size / Dimension 0.187Diax0.362L 4.75mmx9.20mm
Tolerance -20% +80%
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Temperature Coefficient C0G NP0
Terminal Finish SILVER
Voltage - Rated 500V
Additional Feature L-C TYPE CIRCUIT
Capacitance 15pF
Number of Functions 1
Inductance 0.05 μH
Current 10A
Filter Type DATA LINE FILTER
Thread Size M4x0.7
Output Impedance 50Ohm Ω
Insertion Loss (Max) 9 dB
Insulation Resistance-Min 10000MOhm
Compliance
RoHS Status ROHS3 Compliant
