SFBDP5000301MC0
RoHS
RoHS compliant
RoHS compliantPackage Axial, Bushing
Category Filters / Feed Through Capacitors
Description
SFBD Axial Bushing SILVER 1 Feed Through Capacitor 10A 10000MOhm 6.35mm 15dB @ 100MHz
PDF
/
Inventory: 1550
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 12mm
Diameter 6.35mm
Technical
Insulation Resistance-Min 10000MOhm
Output Impedance 50Ohm Ω
Insertion Loss 15dB @ 100MHz
Thread Size 12-32
Filter Type DATA LINE FILTER
Current 10A
Inductance 0.25 μH
Physical Dimension D6.35XH12.0 (mm)/D0.25XH0.472 (inch)
Number of Functions 1
Capacitance 300pF
Additional Feature PI-TYPE CIRCUIT
Voltage - Rated 500V
Terminal Finish SILVER
Temperature Coefficient C0G NP0
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e4
Tolerance ±20%
Size / Dimension 0.250Diax0.472L 6.35mmx12.00mm
Series SFBD
Published 2014
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Package / Case Axial, Bushing
Mounting Type PANEL MOUNT
Supply Chain
Factory Lead Time 11 Weeks
