SFABL5000221MC1
RoHS
RoHS compliant
RoHS compliantPackage Axial, Bushing
Category Filters / Feed Through Capacitors
Description
CAP FEEDTHRU 220PF 500V AXIAL
PDF
/
Inventory: 9149
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Insulation Resistance-Min 10000MOhm
Insertion Loss 12dB @ 100MHz
Thread Size 6-32
Filter Type DATA LINE FILTER
Current 10A
Inductance 0.05 μH
Number of Functions 1
Capacitance 220pF
Additional Feature L-C-TYPE CIRCUIT
Voltage - Rated 500V
Terminal Finish SILVER
Temperature Coefficient C0G NP0
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e4
Tolerance ±20%
Size / Dimension 0.157Diax0.362L 4.00mmx9.20mm
Series SFAB
Published 2014
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Package / Case Axial, Bushing
Mounting Type PANEL MOUNT
Supply Chain
Factory Lead Time 11 Weeks
