SFABC5000470ZC1
RoHS
RoHS compliant
RoHS compliantPackage Axial, Bushing
Category Filters / Feed Through Capacitors
Description
SFAB Axial Bushing SILVER 1 Feed Through Capacitor 10A 10000MOhm 0.157Diax0.362L 4.00mmx9.20mm 1dB @ 100MHz
PDF
/
Buying Options
Total Price: USD $16.68
Unit Price: USD $16.676456
≥1 USD $16.676456
≥200 USD $6.454216
≥500 USD $6.227085
≥1000 USD $6.115488
Inventory: 6887
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mounting Type PANEL MOUNT
Package / Case Axial, Bushing
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2014
Series SFAB
Size / Dimension 0.157Diax0.362L 4.00mmx9.20mm
Tolerance -20% +80%
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Temperature Coefficient C0G NP0
Terminal Finish SILVER
Voltage - Rated 500V
Additional Feature C-TYPE CIRCUIT
Capacitance 47pF
Number of Functions 1
Current 10A
Filter Type FEED THROUGH CAPACITOR
Thread Size 6-32
Insertion Loss 1dB @ 100MHz
Insulation Resistance-Min 10000MOhm
Compliance
RoHS Status ROHS3 Compliant
