SBSMC5000473MXR
RoHS
RoHS compliant
RoHS compliantPackage 2220 (5750 Metric), 3 PC Pad
Category Filters / Feed Through Capacitors
Description
SURFACE MOUNT C AND PI FILTER
PDF
/
Buying Options
Total Price: USD $15.23
Unit Price: USD $15.227014
≥1 USD $15.227014
≥200 USD $6.076101
≥500 USD $5.873915
≥1000 USD $5.772821
Inventory: 9136
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height (Max) 0.133 3.38mm
Width 5mm
Length 5.7mm
Technical
Insertion Loss 43dB @ 100MHz
DC Resistance (DCR) (Max) 0.005Ohm
Filter Type FEED THROUGH CAPACITOR
Current 20A
Physical Dimension L5.7XB5.0XH3.18 (mm)/L0.224XB0.197XH0.125 (inch)
Number of Functions 1
Packing Method TAPE AND REEL
Capacitance 0.047μF
Additional Feature C-TYPE CIRCUIT
Voltage - Rated 500V
Terminal Finish Matte Tin (Sn)
Temperature Coefficient X7R
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Tolerance ±20%
Size / Dimension 0.224Lx0.197W 5.70mmx5.00mm
Series SBSM
Published 2013
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Package / Case 2220 (5750 Metric), 3 PC Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 11 Weeks
