SBSGC5000332MXT
RoHS
RoHS compliant
RoHS compliantPackage 1812 (4532 Metric), 3 PC Pad
Category Filters / Feed Through Capacitors
Description
SURFACE MOUNT C AND PI FILTER
PDF
/
Buying Options
Total Price: USD $3.83
Unit Price: USD $3.829729
≥1 USD $3.829729
≥200 USD $1.482264
≥500 USD $1.431061
≥1000 USD $1.404803
Inventory: 4832
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height (Max) 0.104 2.65mm
Width 3.2mm
Length 5.25mm
Technical
Insertion Loss 34dB @ 100MHz
DC Resistance (DCR) (Max) 0.005Ohm
Filter Type FEED THROUGH CAPACITOR
Current 10A
Physical Dimension L5.25XB3.2XH2.5 (mm)/L0.207XB0.126XH0.098 (inch)
Number of Functions 1
Packing Method TAPE AND REEL
Capacitance 3300pF
Additional Feature C-TYPE CIRCUIT
Voltage - Rated 500V
Temperature Coefficient X7R
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.179Lx0.126W 4.55mmx3.20mm
Series SBSG
Published 2013
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Package / Case 1812 (4532 Metric), 3 PC Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 11 Weeks
