1206J0500223MXTE07
RoHS
RoHS compliant
RoHS compliantPackage 1206 (3216 Metric)
Category Filters / Feed Through Capacitors
Description
Feed Through Capacitors 1206 0.022uF 50v X7R 20% 3-Term C Filter
PDF
/
Buying Options
Total Price: USD $1.8
Unit Price: USD $1.804
≥1 USD $1.804
≥10 USD $1.386
≥100 USD $1.273536
≥500 USD $1.055912
≥1000 USD $0.848989
≥3000 USD $0.742861
Inventory: 5244
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mounting Type Surface Mount
Package / Case 1206 (3216 Metric)
Number of Pins 1206
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Published 2014
Series EMI Filter
Size / Dimension 0.126Lx0.063W 3.20mmx1.60mm
Tolerance ±20%
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Temperature Coefficient X7R
Terminal Finish Matte Tin (Sn) - with Nickel (Ni) barrier
Additional Feature NICKEL BARRIER TERMINATION
Capacitance 0.022μF
Voltage - Rated DC 50V
Number of Functions 1
Current Rating 2A
Physical Dimension L3.2XB1.6XH1.3 (mm)/L0.126XB0.063XH0.051 (inch)
Insulation Resistance 100GOhm
Max Voltage Rating (AC) 50V
Max DC Current 2A
Circuit Type Filter
Filter Type FEED THROUGH CAPACITOR
DC Resistance (DCR) (Max) 0.05Ohm
Insertion Loss 43dB @ 100MHz
Dimensions
Height 1.1mm
Length 3.2mm
Width 1.6mm
Compliance
RoHS Status ROHS3 Compliant
