B85321A2205A501
RoHS
/
Package /
Category Filters / Feed Through Capacitors
Description
Stud AC FEED THROUGH CAPACITOR RoHS Compliant Feed Through Capacitor 500A 1000MHz 251mm 100dB
PDF
/
Buying Options
Total Price: USD $323.95
Unit Price: USD $323.951511
≥1 USD $323.951511
≥200 USD $125.364882
≥500 USD $120.960103
≥1000 USD $118.782002
Inventory: 7099
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Length 251mm
Height 130mm
Diameter 55mm
Technical
Insertion Loss@Frequency-Min 10 dB
Insertion Loss@Frequency-Max 100 dB
Frequency (Min) 0.01MHz
High Pot 2500 V
Current Rating (Max) 500A
Filter Type AC FEED THROUGH CAPACITOR
Frequency (Max) 1000MHz
Max Voltage Rating (DC) 600V
Max DC Current 500A
Max Voltage Rating (AC) 250V
Physical Dimension D55.0XH130.0 (mm)/D2.165XH5.118 (inch)
Current Rating 500A
Depth 55mm
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Termination Stud
Pbfree Code yes
Tolerance 20%
Physical
Mount Through Hole
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 1 month ago)
