B85321A2105A250
RoHS
/
Package /
Category Filters / Feed Through Capacitors
Description
Stud AC FEED THROUGH CAPACITOR RoHS Compliant Feed Through Capacitor 25A 1000MHz 30mm 100dB
PDF
/
Buying Options
Total Price: USD $336.89
Unit Price: USD $336.892766
≥1 USD $336.892766
≥200 USD $134.422579
≥500 USD $129.931149
≥1000 USD $127.711035
Inventory: 10012
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Length 30mm
Height 81mm
Diameter 30mm
Technical
Insertion Loss@Frequency-Min 5 dB
Insertion Loss@Frequency-Max 100 dB
Frequency (Min) 0.01MHz
High Pot 2000 V
Rated Voltage 250V
Current Rating (Max) 25A
Filter Type AC FEED THROUGH CAPACITOR
Frequency (Max) 1000MHz
Max Voltage Rating (DC) 600V
Max DC Current 25A
Max Voltage Rating (AC) 600V
Physical Dimension D30.0XH81.0 (mm)/D1.181XH3.189 (inch)
Current Rating 25A
Depth 129mm
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Termination Stud
Pbfree Code yes
Tolerance 20%
Physical
Mount Wall
