B85121A2105A250
RoHS
/
Package /
Category Filters / Feed Through Capacitors
Description
MATTE TIN AC FEED THROUGH CAPACITOR UL e3 Feed Through Capacitor 25A 1000MHz 30mm 90dB
PDF
/
Inventory: 8209
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Lifecycle Status OBSOLETE (Last Updated: 2 months ago)
Physical
Mount Screw
Technical
Tolerance 20%
JESD-609 Code e3
Termination Stud
Terminal Finish MATTE TIN
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Capacitance 1μF
Voltage - Rated DC 250V
Depth 30mm
Reach Compliance Code unknown
Approval Agency UL
Physical Dimension D20.0XH60.0 (mm)/D0.787XH2.362 (inch)
Operating Frequency 50/60Hz Hz
Max Voltage Rating (AC) 250V
Max Voltage Rating (DC) 600V
Frequency (Max) 1000MHz
Filter Type AC FEED THROUGH CAPACITOR
Current Rating (Max) 25A
High Pot 2000 V
Frequency (Min) 0.01MHz
Insertion Loss@Frequency-Max 90 dB
Insertion Loss@Frequency-Min 5 dB
Dimensions
Diameter 30mm
Height 60mm
Length 30mm
Compliance
RoHS Status RoHS Compliant
