W3F41A4708AT1F
RoHS
/
Package 1206 (3216 Metric), 4 PC Pad
Category Filters / Feed Through Capacitors
Description
W3F4 1206 (3216Metric) 4PC Pad MATTE TIN 4 Feed Through Capacitor 300mA 600mOhm 3.25mm 47pF
PDF
/
Inventory: 7747
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 1206 (3216 Metric), 4 PC Pad
Number of Pins 10
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Published 2003
Series W3F4
Size / Dimension 0.128Lx0.063W 3.25mmx1.60mm
Tolerance -20% +50%
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
ECCN Code EAR99
Temperature Coefficient C0G NP0
Terminal Finish MATTE TIN
Composition Ceramic
Additional Feature PLATED TERMINATION
Capacitance 47pF
Voltage - Rated DC 100V
Packing Method TAPE AND REEL
Number of Functions 1
Terminal Pitch 760μm
Depth 1.6mm
Current Rating 300mA
Case Code (Metric) 3216
Case Code (Imperial) 1206
Dielectric C0G
Insulation Resistance 1GOhm
Voltage 100V
Filter Type FEED THROUGH CAPACITOR
DC Resistance (DCR) (Max) 600mOhm
Number of Capacitors 4
Dimensions
Height 1.2192mm
Length 3.25mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
