PSM4F-103Z-05B

API Technologies Corp
RoHS
/
Package 3-PSM
Category Filters / Feed Through Capacitors
Description Feed Through Capacitors .120SQ.315L 10000PF 5A FEED THRU CIR
PDF
/
Inventory: 7151
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Through Hole
Package / Case 3-PSM
Number of Pins 3

Technical

Operating Temperature -55°C~125°C
Packaging Bulk
Published 2014
Series PSM
Size / Dimension 0.315Lx0.118W 8.00mmx3.00mm
Tolerance -20% +80%
JESD-609 Code e4
Part Status Discontinued
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Terminal Finish Silver (Ag)
Voltage - Rated 200V
Capacitance 10000pF
Number of Functions 1
Current 5A
Filter Type DATA LINE FILTER
DC Resistance (DCR) (Max) 0.5mOhm
Insulation Resistance-Min 1000MOhm

Dimensions

Height 2.9972mm
Length 8.26mm

Compliance

RoHS Status RoHS Compliant
