PSM4-821M-02B
RoHS
/
Package 3-PSM
Category Filters / Feed Through Capacitors
Description
Feed Through Capacitors .120SQ.315L 820PF2A FEED THRU CIR
PDF
/
Inventory: 4588
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Package / Case 3-PSM
Number of Pins 3
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2014
Series PSM
Size / Dimension 0.315Lx0.118W 8.00mmx3.00mm
Tolerance ±20%
Part Status Discontinued
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Voltage - Rated 200V
Capacitance 820pF
Current 2A
DC Resistance (DCR) (Max) 0.5mOhm
Dimensions
Height 2.9972mm
Length 8.001mm
Width 2.9972mm
Height (Max) 0.118 3.00mm
Compliance
RoHS Status Non-RoHS Compliant
