PSM4-402Z-20B
RoHS
/
Package 3-PSM
Category Filters / Feed Through Capacitors
Description
EMI Filter Low Pass 20A 125VAC/200VDC Flat Style SMD Bulk
PDF
/
Buying Options
Total Price: USD $3.61
Unit Price: USD $3.607726
≥1 USD $3.607726
≥10 USD $3.403512
≥100 USD $3.210854
≥500 USD $3.029112
≥1000 USD $2.857651
Inventory: 1331
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Length 8mm
Height 2.9972mm
Technical
DC Resistance (DCR) (Max) 0.5mOhm
Filter Type FEED THROUGH CAPACITOR
Max Current Rating 20A
Depth 3mm
Number of Functions 1
Capacitance 4000pF
HTS Code 8504.50.80.00
Additional Feature C-TYPE CIRCUIT
Voltage - Rated 200V
Terminal Finish Silver (Ag)
ECCN Code EAR99
Termination Flat
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Discontinued
JESD-609 Code e4
Tolerance -20% +80%
Size / Dimension 0.315Lx0.118W 8.00mmx3.00mm
Series PSM
Published 2014
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Number of Pins 3
Package / Case 3-PSM
Mounting Type SURFACE MOUNT
Supply Chain
Factory Lead Time 12 Weeks
