PSM4-252P-05B
RoHS
/
Package 3-PSM
Category Filters / Feed Through Capacitors
Description
Feed Through Capacitors .120SQ.315L 2500PF 5A FEED THRU CIR
PDF
/
Inventory: 1978
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Package / Case 3-PSM
Number of Pins 3
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2014
Series PSM
Size / Dimension 0.315Lx0.118W 8.00mmx3.00mm
Tolerance 0% +100%
Part Status Discontinued
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Voltage - Rated 200V
Capacitance 2500pF
Voltage - Rated DC 200V
Current Rating 20A
Insulation Resistance 1GOhm
Current 5A
DC Resistance (DCR) (Max) 0.5mOhm
Dimensions
Height 2.9972mm
Length 8.001mm
Width 3mm
Height (Max) 0.118 3.00mm
Compliance
RoHS Status Non-RoHS Compliant
