PSM4-152M-20T0
RoHS
/
Package 3-PSM
Category Filters / Feed Through Capacitors
Description
EMI Filter Low Pass 20A 125VAC/200VDC Flat Style SMD T/R
PDF
/
Buying Options
Total Price: USD $0.8
Unit Price: USD $0.80465
≥1 USD $0.80465
≥10 USD $0.66025
≥100 USD $0.63935
≥500 USD $0.6194
≥1000 USD $0.5985
Inventory: 21005
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Length 8mm
Height 2.9972mm
Technical
Insulation Resistance-Min 1000MOhm
DC Resistance (DCR) (Max) 0.5mOhm
Filter Type FEED THROUGH CAPACITOR
Max Current Rating 20A
Depth 3mm
Number of Functions 1
Packing Method TAPE AND REEL
Capacitance 1500pF
HTS Code 8504.50.80.00
Voltage - Rated 200V
ECCN Code EAR99
Termination Through Hole
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Discontinued
Tolerance ±20%
Size / Dimension 0.315Lx0.118W 8.00mmx3.00mm
Series PSM
Published 2014
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Number of Pins 3
Package / Case 3-PSM
Mounting Type SURFACE MOUNT
