PSM4-131P-20B
RoHS
/
Package 3-PSM
Category Filters / Feed Through Capacitors
Description
EMI Filter Low Pass 20A 125VAC/200VDC Flat Style SMD Bulk
PDF
/
Inventory: 2639
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Package / Case 3-PSM
Number of Pins 3
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2014
Series PSM
Size / Dimension 0.315Lx0.118W 8.00mmx3.00mm
Tolerance 0% +100%
Part Status Discontinued
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Flat
ECCN Code EAR99
Voltage - Rated 200V
HTS Code 8504.50.80.00
Capacitance 130pF
Depth 3mm
Max Current Rating 20A
Filter Type FEED THROUGH CAPACITOR
DC Resistance (DCR) (Max) 0.5mOhm
Dimensions
Height 2.9972mm
Compliance
RoHS Status Non-RoHS Compliant
