54F-863-005
RoHS
/
Package Axial, Bushing
Category Filters / Feed Through Capacitors
Description
EMI Feedthrough Filters M4 C CIRCUIT 100DC, A0A, 100pF
PDF
/
Inventory: 6812
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Length 7.1882mm
Technical
Insertion Loss (dB) 3 dB
Insertion Loss 3dB @ 100MHz
DC Resistance (DCR) (Max) 10mOhm
Thread Size M3
Current 10A
Capacitance 100pF
Voltage - Rated 100V
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Discontinued
Size / Dimension 0.157Diax0.283L 4.00mmx7.18mm
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Package / Case Axial, Bushing
Mounting Type Chassis Mount
Mount Chassis Mount
