54-874-011
RoHS
/
Package Axial, Bushing
Category Filters / Feed Through Capacitors
Description
EMI Filter Spin 5A 50VDC AXL Panel Mount
PDF
/
Buying Options
Total Price: USD $6.74
Unit Price: USD $6.741775
≥1 USD $6.741775
≥10 USD $6.360166
≥100 USD $6.000149
≥500 USD $5.660521
≥1000 USD $5.340109
Inventory: 1212
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Through Hole
Package / Case Axial, Bushing
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Size / Dimension 0.105Diax0.221L 2.67mmx5.62mm
Tolerance -20% +50%
JESD-609 Code e4
Part Status Discontinued
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Axial
ECCN Code EAR99
Terminal Finish GOLD
Additional Feature C-TYPE CIRCUIT
HTS Code 8504.50.80.00
Capacitance 39pF
Packing Method BAG
Number of Functions 1
Depth 2.67mm
Physical Dimension D2.67XH3.56 (mm)/D0.105XH0.14 (inch)
Voltage 50V
Max Current Rating 5A
Max Voltage Rating (DC) 50V
Filter Type FEED THROUGH CAPACITOR
Thread Size 2-56
Rated Current 5A
DC Resistance (DCR) (Max) 5mOhm
Insulation Resistance-Min 1000MOhm
Dimensions
Diameter 2.67mm
Height 3.56mm
Compliance
RoHS Status Non-RoHS Compliant
