ADP123-EVALZ
RoHS
RoHS compliant
RoHS compliantPackage TSOT
Category Development Boards, Kits, Programmers / Evaluation Boards - Linear Voltage Regulators
Description
ANALOG DEVICES ADP123-EVALZEvaluation Board for ADP123 Low Dropout Voltage Regulator
PDF
/
Buying Options
Total Price: USD $64.01
Unit Price: USD $64.0112
≥1 USD $64.0112
Inventory: 25
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Technical
Channels per IC 1 - Single
Board Type Fully Populated
Regulator Type Positive Adjustable
Power Supply Rejection Ratio (PSRR) 60dB
Evaluation Kit Yes
Min Output Voltage 800mV
Supplied Contents Board(s)
Utilized IC / Part ADP123
Max Input Voltage 5.5V
Min Input Voltage 2.3V
Voltage - Output 0.8V~5V
Max Output Voltage 5V
Current - Output 350mA
Max Supply Current 170μA
Nominal Supply Current 45μA
Voltage - Input 2.3V~5.5V
Operating Supply Current 45μA
Max Output Current 300mA
Base Part Number ADP123
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Packaging Box
Physical
Number of Pins 0
Package / Case TSOT
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 4 weeks ago)
Factory Lead Time 8 Weeks
