C8051F005DK
RoHS
/
Package /
Category Development Boards, Kits, Programmers / Evaluation Boards - Embedded - MCU, DSP
Description
SILICON LABORATORIES C8051F005DK DEV KIT, FOR C8051F005
PDF
/
Inventory: 5704
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 2 Weeks
Physical
Mounting Type Fixed
Surface Mount YES
Weight 50.008559mg
Technical
Published 2000
Part Status Not For New Designs
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 32
Type MCU 8-Bit
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Pin Count 32
JESD-30 Code S-PQFP-G32
Operating Temperature (Min) -40°C
Operating Supply Voltage 15V
Supply Voltage-Max (Vsup) 3.6V
Temperature Grade INDUSTRIAL
Number of Channels 5
Interface RS-232, USB
Number of I/O 8
Speed 20 MHz
RAM Size 2.3kB
Number of Bits 8
Core Processor 8051
Clock Frequency 20MHz
Bit Size 8
Has ADC YES
DMA Channels NO
Data Bus Width 8b
PWM Channels NO
DAC Channels YES
Utilized IC / Part C8051F0xx
Density 250 kb
Evaluation Kit Yes
Contents Board(s), Cable(s), Power Supply, USB Debug Adapter Programmer
Board Type Evaluation Platform
ROM Programmability FLASH
Dimensions
Height Seated (Max) 1.6mm
Length 7mm
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
