STEVAL-ISA053V1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Development Boards, Kits, Programmers / Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS
Description
BOARD EVALUATION FOR PM6680
PDF
/
Inventory: 8596
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Voltage - Input 6V~28V
Current - Output 5A 5A 100mA
Voltage - Output 1.05V 1.5V 5V
Frequency - Switching 200kHz 300kHz
Utilized IC / Part PM6680
Supplied Contents Board(s)
Evaluation Kit Yes
Board Type Fully Populated
Main Purpose DC/DC, Step Down with LDO
Outputs and Type 3, Non-Isolated
Regulator Topology Buck
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
