NCP1392LCDTVGEVB

ON Semiconductor
RoHS
RoHS RoHS compliant
Package /
Category Development Boards, Kits, Programmers / Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS
Description Evaluation Board For NCP1392HV, HB DRVW/OSC
PDF
/
Inventory: 7614
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Radiation Hardening No

Technical

Regulator Topology Flyback
Outputs and Type 4, Isolated
Main Purpose AC/DC, Primary Side
Power - Output 220W
Board Type Fully Populated
Evaluation Kit Yes
Supplied Contents Board(s)
Utilized IC / Part NCP1392
Voltage - Output 5V 5V 12V 24V
Current - Output 6A 3A 2A 2A
Voltage - Input 90V~265VAC
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
