NCP1230GEVB

ON Semiconductor
RoHS
/
Package /
Category Development Boards, Kits, Programmers / Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS
Description EVAL BOARD FOR NCP1230G
PDF
/
Inventory: 7056
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Technical

Published 2005
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Voltage - Input 85V~265VAC
Current - Output 4.74A
Voltage - Output 18.6V
Frequency - Switching 47kHz
Utilized IC / Part NCP1230
Supplied Contents Board(s)
Evaluation Kit Yes
Board Type Fully Populated
Power - Output 90W
Main Purpose AC/DC, Primary Side
Outputs and Type 1, Isolated
Regulator Topology Flyback

Compliance

RoHS Status RoHS Compliant
