ADM00566
RoHS
RoHS compliant
RoHS compliantPackage /
Category Development Boards, Kits, Programmers / Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS
Description
MCP1661 High-Voltage Boost and SEPIC Converters Evaluation Board
PDF
/
Buying Options
Total Price: USD $55.62
Unit Price: USD $55.616
≥1 USD $55.616
Inventory: 78
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Technical
Regulator Topology Boost, SEPIC
Outputs and Type 2, Non-Isolated
Main Purpose DC/DC, Step Up
Board Type Fully Populated
Evaluation Kit Yes
Supplied Contents Board(s)
Utilized IC / Part MCP1661
Frequency - Switching 500kHz
Voltage - Output 3.3V 12V
Current - Output 125mA
Voltage - Input 2.4V~5.5V
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2014
Supply Chain
Factory Lead Time 14 Weeks
