MAX1513EVKIT

Maxim Integrated
RoHS
RoHS RoHS compliant
Package /
Category Development Boards, Kits, Programmers / Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS
Description Power Management IC Development Tools MAX1513/14 Eval Kit
PDF
/
Inventory: 5320
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Technical

Regulator Topology Boost
Outputs and Type 5, Non-Isolated
Main Purpose Special Purpose DC/DC, LCD Supply
Board Type Fully Populated
Evaluation Kit Yes
Supplied Contents Board(s)
Utilized IC / Part MAX1513
Frequency - Switching 1.5MHz
Voltage - Output 3.3V 14.7V 15V 25V -10V
Current - Output 500mA 500mA 50mA 50mA 25mA
Voltage - Input 4.5V~5.5V
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Published 2004

Supply Chain

Factory Lead Time 6 Weeks
