RoHS
RoHS compliant
RoHS compliantPackage /
Category Development Boards, Kits, Programmers / Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS
Description
BOARD EVAL FOR LT1506CS8
PDF
/
Buying Options
Total Price: USD $124.53
Unit Price: USD $124.5288
≥1 USD $124.5288
Inventory: 27
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Technical
Regulator Topology Buck
Outputs and Type 1, Non-Isolated
Main Purpose DC/DC, Step Down
Board Type Fully Populated
Evaluation Kit Yes
Supplied Contents Board(s)
Utilized IC / Part LT1506
Frequency - Switching 500kHz
Voltage - Output 3.3V
Current - Output 4A
Voltage - Input 4.5V~15V
Base Part Number LT1506
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2000
Physical
Number of Pins 0
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 1 week ago)
Factory Lead Time 8 Weeks
