EVQ-V5C00315B
RoHS
RoHS compliant
RoHS compliantPackage /
Category Sensors, Transducers / Encoders
Description
PANASONIC EVQ-V5C00315B ENCODER, CENTER SPACE, 15 PULSE, 30 DETENTS
PDF
/
Buying Options
Total Price: USD $2.82
Unit Price: USD $2.816
≥1 USD $2.816
≥10 USD $2.5432
≥100 USD $2.37688
≥500 USD $2.178528
≥1000 USD $2.032624
≥3000 USD $1.912768
Inventory: 229
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC Unknown
Technical
Rotational Life (Cycles Min) 30K
Pulses per Revolution 9
Detent Yes
Encoder Type Mechanical
Built in Switch No
Operating Supply Voltage 10V
Output Type Quadrature (Incremental)
Actuator Type 27mm Open Center
Termination Style PC Pin
Orientation Vertical
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series EVQV
Published 2007
Physical
Mounting Type PCB, Through Hole
Mount PCB, Through Hole
Supply Chain
Factory Lead Time 13 Weeks
