EVE-UPCAH516B image
Favorite
EVE-UPCAH516B image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Sensors, Transducers / Encoders
Description Smd, Push Force 4.0N, Travel 1.5Mm, Torque 14Mnm, 16Pulse/32Det
PDF
/
Buying Options
Total Price: USD $4.14
Unit Price: USD $4.136
≥1 USD $4.136
≥10 USD $3.74176
≥100 USD $3.49624
≥500 USD $3.204608
≥1000 USD $2.9898
≥3000 USD $2.81358
Inventory: 1607
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status RoHS Compliant

Technical

Rotational Life (Cycles Min) 30K
Pulses per Revolution 16
Detent Yes
Encoder Type Mechanical
Built in Switch Yes
Number of Channels 2
Output Type Quadrature (Incremental)
Actuator Type 8mm Dia Flatted End
Termination Style Solder Tab
Orientation Vertical
Voltage - Supply 5V
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2012

Physical

Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 8 Weeks
