EVE-PDBRG508B image
Favorite
EVE-PDBRG508B image
Favorite
RoHS
RoHS RoHS compliant
Package Radial
Category Sensors, Transducers / Encoders
Description Radial EVEP PC Pin Quadrature (Incremental) Mechanical Encoder 10V
PDF
/
Buying Options
Total Price: USD $10.43
Unit Price: USD $10.428
≥1 USD $10.428
≥10 USD $8.9496
≥100 USD $8.38024
≥500 USD $7.683808
≥1000 USD $7.177104
≥3000 USD $6.75488
Inventory: 238
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant

Technical

Nominal Supply Voltage (DC) 10V
Rotational Life (Cycles Min) 1M
Pulses per Revolution 8
Detent Yes
Encoder Type Mechanical
Built in Switch Yes
Number of Channels 2
Operating Supply Voltage 5V
Output Type Quadrature (Incremental)
Actuator Type 12mm Dia Round End
Termination Style PC Pin
Orientation Vertical
Number of Positions 8
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series EVEP
Published 2011

Physical

Number of Pins 5
Package / Case Radial
Mounting Type PCB, Through Hole
Mount PCB, Through Hole

Supply Chain

Factory Lead Time 10 Weeks
