62S15-H9-PH

Grayhill Inc.
RoHS
RoHS RoHS compliant
Package /
Category Sensors, Transducers / Encoders
Description ROTARY ENCODER OPTICAL 24PPR
PDF
/
Buying Options
Total Price: USD $46.04
Unit Price: USD $46.04087
≥1 USD $46.04087
≥10 USD $43.434787
≥100 USD $40.976215
≥500 USD $38.656802
≥1000 USD $36.468681
Inventory: 2841
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status RoHS Compliant

Technical

Rotational Life (Cycles Min) 1M
Pulses per Revolution 24
Detent Yes
Encoder Type Optical
Optoelectronic Device Type ROTARY POSITION ENCODER
Configuration SINGLE, 2 CHANNELS
Output Type Quadrature (Incremental)
Actuator Type 1/4 Dia Flatted End
Termination Style PC Pin
Number of Functions 1
Orientation Vertical
Voltage - Supply 5V
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Tin (Sn)
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series 62S
Published 2010

Physical

Number of Pins 6
Mounting Type PCB, Through Hole
Mount PCB, Through Hole

Supply Chain

Factory Lead Time 16 Weeks
