HRPG-AD32#13R
RoHS
RoHS compliant
RoHS compliantPackage /
Category Sensors, Transducers / Encoders
Description
Optical Encoder Rotary Incremental Flat Straight Digital Square Wave Bracket Mount PC Pins 32CPR
PDF
/
Buying Options
Total Price: USD $57.53
Unit Price: USD $57.5256
≥1 USD $57.5256
≥10 USD $53.1696
≥100 USD $49.74904
≥500 USD $45.706496
≥1000 USD $42.752688
≥3000 USD $40.420776
Inventory: 153
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Rotational Life (Cycles Min) 1M
Pulses per Revolution 32
Detent Yes
Encoder Type Optical
Built in Switch No
Optoelectronic Device Type ROTARY POSITION ENCODER
Number of Channels 2
Operating Supply Voltage 5.5V
Output Type Quadrature (Incremental)
Actuator Type 1/4 Dia Flatted End
Termination Style PC Pin
Number of Functions 1
Orientation Vertical
Voltage - Supply 5V
Min Operating Temperature 0°C
Max Operating Temperature 70°C
Terminal Finish Nickel (Ni)
ECCN Code EAR99
Termination PC Pins
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series HRPG
Published 2006
Physical
Number of Pins 5
Mounting Type PCB, Through Hole
Mount PCB, Through Hole
Supply Chain
Factory Lead Time 12 Weeks
