HEDT-9101#I00
RoHS
RoHS compliant
RoHS compliantPackage /
Category Sensors, Transducers / Encoders
Description
ROTARY ENCODER OPTICAL 512PPR
PDF
/
Inventory: 8144
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Chassis Mount
Surface Mount NO
Mounting Feature THROUGH HOLE MOUNT
Technical
Published 2010
Series HEDT
JESD-609 Code e4
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Voltage - Supply 5V
Orientation Right Angle
Number of Functions 1
Reach Compliance Code compliant
Termination Style Terminal Pins
Operating Temperature (Max) 125°C
Actuator Type Codewheel Not Included
Operating Temperature (Min) -40°C
Output Type Quadrature (Incremental)
Configuration SINGLE, 2 CHANNELS
Optoelectronic Device Type ROTARY POSITION ENCODER
Encoder Type Optical
Detent No
Pulses per Revolution 512
Compliance
RoHS Status RoHS Compliant
