HEDS-9732#T54

Broadcom Limited
RoHS
/
Package /
Category Sensors, Transducers / Encoders
Description ROTARY ENCODER OPTICAL 2000PPR
PDF
/
Inventory: 6615
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mounting Type Chassis Mount
Surface Mount NO
Mounting Feature THROUGH HOLE MOUNT

Technical

Series HEDS
JESD-609 Code e4
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
HTS Code 8543.70.96.50
Subcategory Other Optoelectronics
Voltage - Supply 3.3VDC
Orientation Vertical
Number of Functions 1
Termination Style Terminal Pins
Operating Temperature (Max) 70°C
Actuator Type Codewheel Not Included
Operating Temperature (Min) -40°C
Output Type Quadrature (Incremental)
Number of Elements 2
Configuration SINGLE, 2 CHANNELS
Optoelectronic Device Type ROTARY POSITION ENCODER
Encoder Type Optical
On-State Current-Max 0.005A
Detent No
Pulses per Revolution 2000
Output Circuit Type Amplifier
Gap Size 1.7mm

Compliance

RoHS Status Non-RoHS Compliant
