HEDS-9731#J54
RoHS
RoHS compliant
RoHS compliantPackage /
Category Sensors, Transducers / Encoders
Description
ROTARY ENCODER OPTICAL 1024PPR
PDF
/
Inventory: 3746
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Pulses per Revolution 1024
Detent No
Encoder Type Optical
Optoelectronic Device Type ROTARY POSITION ENCODER
Number of Channels 2
Operating Supply Voltage 5V
Output Type Quadrature (Incremental)
Operating Temperature (Min) -40°C
Actuator Type Codewheel Not Included
Operating Temperature (Max) 70°C
Termination Style Terminal Pins
Number of Functions 1
Orientation Right Angle
Voltage - Supply 2.8V~5.2V
HTS Code 8543.70.96.50
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Termination Through Hole
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e4
Series HEDS
Packaging Bulk
Physical
Mounting Type Chassis Mount
Mount Chassis Mount
Supply Chain
Factory Lead Time 16 Weeks
