HEDS-9731#B51
RoHS
/
Package /
Category Sensors, Transducers / Encoders
Description
ROTARY ENCODER OPTICAL 1000PPR
PDF
/
Buying Options
Total Price: USD $5.91
Unit Price: USD $5.9071
≥1 USD $5.9071
≥10 USD $4.8469
≥100 USD $4.6949
≥500 USD $4.54385
≥1000 USD $4.3928
Inventory: 11002
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Technical
Pulses per Revolution 1000
Detent No
Encoder Type Optical
Optoelectronic Device Type ROTARY/LINEAR POSITION ENCODER
Configuration SINGLE, 2 CHANNELS
Output Type Quadrature (Incremental)
Operating Temperature (Min) -40°C
Actuator Type Codewheel Not Included
Operating Temperature (Max) 70°C
Termination Style Terminal Pins
Number of Functions 1
Orientation Right Angle
Voltage - Supply 2.8V~5.2V
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e4
Series HEDS
Published 2010
Physical
Mounting Type Chassis Mount
