HEDS-9731#A50
RoHS
RoHS compliant
RoHS compliantPackage /
Category Sensors, Transducers / Encoders
Description
ROTARY ENCODER OPTICAL 500PPR
PDF
/
Buying Options
Total Price: USD $15.57
Unit Price: USD $15.5672
≥1 USD $15.5672
≥10 USD $13.3936
≥100 USD $12.52328
≥500 USD $11.485408
≥1000 USD $10.715408
≥3000 USD $10.04564
Inventory: 430
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Chassis Mount
Mounting Type Chassis Mount
Technical
Packaging Bulk
Series HEDS
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Through Hole
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
HTS Code 8543.70.96.50
Voltage - Supply 2.8V~5.2V
Orientation Right Angle
Number of Functions 1
Current Rating 5mA
Termination Style Terminal Pins
Actuator Type Codewheel Not Included
Output Type Quadrature (Incremental)
Operating Supply Voltage 5V
Number of Channels 2
Optoelectronic Device Type ROTARY POSITION ENCODER
Encoder Type Optical
Detent No
Pulses per Revolution 500
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
