HEDS-9720#P55

Broadcom Limited
RoHS
RoHS RoHS compliant
Package /
Category Sensors, Transducers / Encoders
Description Optical Encoder Linear Incremental Straight Digital Through Hole PC Pins
PDF
/
Inventory: 9673
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Technical

Gap Size 1.7mm
Pulses per Revolution 150 LPI
Detent No
On-State Current-Max 0.005A
Encoder Type Optical
Optoelectronic Device Type LINEAR POSITION ENCODER
Number of Channels 2
Number of Elements 2
Operating Supply Voltage 5V
Output Type Quadrature (Incremental)
Actuator Type Codestrip Not Included
Termination Style Terminal Pins
Number of Functions 1
Orientation Vertical
Subcategory Other Optoelectronics
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Termination Through Hole
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e4
Series HEDS
Packaging Bulk

Physical

Number of Pins 4
Mounting Type Chassis Mount
Mount Chassis Mount, Screw
Contact Plating Gold

Supply Chain

Factory Lead Time 16 Weeks
