HEDS-9701#E54

Broadcom Limited
RoHS
RoHS RoHS compliant
Package /
Category Sensors, Transducers / Encoders
Description Optical Encoder Rotary Incremental Straight Digital Through Hole PC Pins 200CPR
PDF
/
Buying Options
Total Price: USD $10.15
Unit Price: USD $10.15455
≥1 USD $10.15455
≥10 USD $8.3315
≥100 USD $8.0712
≥500 USD $7.8109
≥1000 USD $7.5506
Inventory: 2506
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Technical

Gap Size 1.7mm
Output Circuit Type Amplifier
Pulses per Revolution 200
Detent No
On-State Current-Max 0.005A
Encoder Type Optical
Optoelectronic Device Type ROTARY POSITION ENCODER
Number of Channels 2
Operating Supply Voltage 5V
Output Type Quadrature (Incremental)
Actuator Type Codewheel Not Included
Termination Style Terminal Pins
Number of Functions 1
Orientation Right Angle
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Termination Through Hole
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e4
Series HEDS
Packaging Bulk

Physical

Number of Pins 4
Mounting Type Chassis Mount
Mount Chassis Mount

Supply Chain

Factory Lead Time 16 Weeks
