HEDS-9141#A00
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Sensors, Transducers / Encoders
Description
Module HEDS Terminal Pins Quadrature with Index (Incremental) Optical Encoder 5V 100C
PDF
/
Buying Options
Total Price: USD $10.74
Unit Price: USD $10.73975
≥1 USD $10.73975
≥10 USD $8.8122
≥100 USD $8.5367
≥500 USD $8.2612
≥1000 USD $7.9857
Inventory: 1109
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Chassis Mount
Mounting Type Chassis Mount
Package / Case Module
Number of Pins 7
Technical
Series HEDS
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Through Hole
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Max Operating Temperature 100°C
Min Operating Temperature -40°C
Orientation Right Angle
Number of Functions 1
Termination Style Terminal Pins
Actuator Type Codewheel Not Included
Output Type Quadrature with Index (Incremental)
Operating Supply Voltage 5V
Number of Channels 3
Optoelectronic Device Type ROTARY POSITION ENCODER
Encoder Type Optical
Detent No
Pulses per Revolution 500
Compliance
RoHS Status ROHS3 Compliant
