HEDS-9100#S00
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Sensors, Transducers / Encoders
Description
Optical Encoder Rotary Incremental Straight Digital Through Hole PC Pins 50CPR
PDF
/
Buying Options
Total Price: USD $27.12
Unit Price: USD $27.115736
≥1 USD $27.115736
≥10 USD $25.580886
≥100 USD $24.13291
≥500 USD $22.7669
≥1000 USD $21.478201
Inventory: 6817
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Gap Size 1.78mm
Nominal Supply Voltage (DC) 5V
Pulses per Revolution 50
Detent No
Encoder Type Optical
Optoelectronic Device Type ROTARY POSITION ENCODER
Number of Channels 2
Operating Supply Voltage 5V
Output Type Quadrature (Incremental)
Actuator Type Codewheel Not Included
Termination Style Terminal Pins
Number of Functions 1
Orientation Vertical
Min Operating Temperature -40°C
Max Operating Temperature 100°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Termination PC Pins
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series HEDS
Physical
Number of Pins 5
Package / Case Module
Mounting Type Chassis Mount
Mount Chassis Mount
Supply Chain
Factory Lead Time 12 Weeks
