HEDS-9040#J00
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Sensors, Transducers / Encoders
Description
BROADCOM LIMITED HEDS-9040#J00 ENCODER, ROTARY, 1024PPR, 3CH
PDF
/
Buying Options
Total Price: USD $41.88
Unit Price: USD $41.8792
≥1 USD $41.8792
≥10 USD $37.48272
≥100 USD $35.17976
≥500 USD $32.247776
≥1000 USD $30.153728
≥3000 USD $28.269208
Inventory: 503
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Chassis Mount
Mounting Type Chassis Mount
Package / Case Module
Technical
Published 2002
Series HEDS
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pins
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Max Operating Temperature 100°C
Min Operating Temperature -40°C
Orientation Vertical
Number of Functions 1
Current Rating 5mA
Frequency 100kHz
Termination Style Terminal Pins
Actuator Type Codewheel Not Included
Output Type Quadrature with Index (Incremental)
Operating Supply Voltage 5V
Number of Channels 3
Optoelectronic Device Type ROTARY POSITION ENCODER
Encoder Type Optical
Detent No
Pulses per Revolution 1024
Dimensions
Width 26.7mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
