HEDS-5700#I12
RoHS
/
Package /
Category Sensors, Transducers / Encoders
Description
ROTARY ENCODER OPTICAL 512PPR
PDF
/
Inventory: 6589
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Technical
Rotational Life (Cycles Min) 1M
Pulses per Revolution 512
Detent Yes
Encoder Type Optical
Built in Switch No
Optoelectronic Device Type ROTARY POSITION ENCODER
Configuration SINGLE, 2 CHANNELS
Output Type Quadrature (Incremental)
Operating Temperature (Min) -20°C
Actuator Type 1/4 Dia Flatted End
Operating Temperature (Max) 85°C
Termination Style Terminal Pins
Number of Functions 1
Orientation Vertical
Voltage - Supply 5V
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e4
Series HEDS
Published 2006
Physical
Mounting Type Panel Mount
