HEDS-5645#H14
RoHS
RoHS compliant
RoHS compliantPackage Metal
Category Sensors, Transducers / Encoders
Description
Optical Encoder Rotary Incremental Round with Slot Straight Digital Through Hole PC Pins 400CPR
PDF
/
Buying Options
Total Price: USD $41.93
Unit Price: USD $41.933429
≥1 USD $41.933429
≥10 USD $39.55984
≥100 USD $37.320606
≥500 USD $35.208122
≥1000 USD $33.215211
Inventory: 1169
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Plating Gold
Mount Chassis Mount, Screw
Mounting Type Chassis Mount, Motors
Package / Case Metal
Number of Pins 5
Technical
Published 2014
Series HEDS
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pins
ECCN Code EAR99
Max Operating Temperature 100°C
Min Operating Temperature -40°C
Orientation Vertical
Number of Functions 1
Termination Style Terminal Pins
Actuator Type 5mm Open Center
Output Type Quadrature with Index (Incremental)
Operating Supply Voltage 5V
Number of Channels 3
Optoelectronic Device Type ROTARY POSITION ENCODER
Encoder Type Optical
Detent No
Pulses per Revolution 400
Compliance
RoHS Status ROHS3 Compliant
