HEDS-5640#E06
RoHS
RoHS compliant
RoHS compliantPackage /
Category Sensors, Transducers / Encoders
Description
HEDS Terminal Pins Quadrature with Index (Incremental) 200 Optical Encoder 5V 100C
PDF
/
Buying Options
Total Price: USD $46.67
Unit Price: USD $46.67092
≥1 USD $46.67092
≥10 USD $44.029176
≥100 USD $41.53696
≥500 USD $39.185803
≥1000 USD $36.96774
Inventory: 930
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Pulses per Revolution 200
Detent No
Encoder Type Optical
Optoelectronic Device Type ROTARY POSITION ENCODER
Configuration SINGLE, 3 CHANNELS
Output Type Quadrature with Index (Incremental)
Operating Temperature (Min) -40°C
Actuator Type 1/4 Open Center
Operating Temperature (Max) 100°C
Termination Style Terminal Pins
Number of Functions 1
Orientation Vertical
Voltage - Supply 5V
HTS Code 8543.70.96.50
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series HEDS
Published 2014
Physical
Mounting Feature THROUGH HOLE MOUNT
Surface Mount NO
Mounting Type Chassis Mount, Motors
Supply Chain
Factory Lead Time 12 Weeks
